MH6019-19332
Description
FOR PELLET STOVE, OVEN, LAB EQUIPMENT
Features
1.Rated Voltage/Frequency：240v/50hz
2.Current（A):H: 0.3 M: 0.2 L:0.14
3.Input Power（W）:H: 33 M: 25 L:20
4.Speed（RPM):H: 1650 M: 1200 L:950
5.Hi-Pot TEST:1800Vac 50Hz,3mA,1S
6.Start Voltage: 161V/50Hz
6.Bearing Type:BALL BEARING
7.Insulation Class:H
8.Wind Speed(m/s):H:5 M: 3.5 L:3
9.Air Volume（CFM):H: 119 M: 90 L:70
14.Protect method： TP
15.Application:Pellet Stove, OVEN, Lab Equipment
16.Agency：ETL/CE/CCC
